Valtra Section Control

accurate application Precise control

Save inputs and maximise yields with Section Control

Section Control 96 with Miltiboom by Valtra uses GNSS (Global Navigation Satellite System) and the SmartTouch interface to automatically turn on and off individual sections of ISOBUS implements. Save time and money by minimising gaps, eliminating overlaps, and reducing the amount of inputs used.

Request a Quote from your dealer

Section Control 96 with Multiboom

Valtra Section Control works with ISOBUS implements to control up to 96 individual sections of a sprayer, seed drill, spreader or row crop cultivator. The Multiboom feature enables up to three individual booms to be automatically controlled. This means both front and rear-mounted implements can be used simultaneously. Everything is smoothly and easily controlled from the SmartTouch interface.

Your Benefits

Greater productivity

Get more done, even when working at speed. Modern implements are becoming wider, and more capable of working at speed. By controlling up to 96 sections, overlaps can be eliminated, and sections can be quickly and automatically turned off at the headland.

100% coverage

Section Control 96 with Multiboom safeguards against missed areas where disease and weeds can take hold. By switching off individual sections of the implement as it meets the headland or previously treated area double application is avoided. You get 100% coverage to the entire field. No more. No less.

Bigger savings

Overlaps are automatically eradicated, saving up to 5% on the cost of inputs such as seeds, fertilisers and plant protection products. As everything is controlled through the SmartTouch interface there is no need to invest in additional hardware. Controlling sections of multiple booms at once means doing more in fewer passes for quicker, more efficient work.

Easy to use

Section Control 96 with Multiboom is controlled simply and easily from the touchscreen of the SmartTouch armrest. From one place all ISOBUS implements can be controlled without the need for additional terminals and cables. With Valtra Guide and Section Control, you can work in any visibility.

Precise precision

Section Control 96 works in connection with Valtra Guide auto-guidance, available with up to centimetre accuracy. Overlap settings can be easily controlled, for example, to ensure that when precision drilling the last seed falls either exactly on the first line of the headland or with a 'half-row- spacing. When an existing field boundary has been plotted, Headland mode allows the inside of a field to be worked before the headland, resulting in less soil compaction when cultivating and seeding.

multiboom and isobus

Multiboom enables Section Control functionality across multiple ISOBUS implements on up to three booms, no matter whether the implements are front or rear-mounted, or both. Up to 96 individual sections or elements of implements can be automatically switched on or off.

as easy as plug and play

ISOBUS-compatible seed drills, sprayers, spreaders, and row crop cultivators can be controlled by Section Control 96 with Multiboom from the touchscreen of the SmartTouch armrest. Simply plug the ISOBUS implement into the tractor and all relevant data are transferred. The SmartTouch Extend second screen can also be used to provide an overview when working. Fast and accurate direction recognition automatically detect when the tractor is reversing.
